Schematic Diagram
Canister
Canister is filled with charcoal and absorbs evaporated vapor in fuel
tank. The gathered fuel vapor in canister is drawn into the intake manifold
by the ECM/PCM when appropri ...
Cylinder Block Reassembly
1.
Install the oil jet (A).
Tightening torque :
24.5 ~ 29.4 N.m (2.5 ~ 3.0 kgf.m, 18.1 ~ 21.7 lb-ft)
...
Removal
1.
Place the shift lever into the "N" position.
2.
Remove the air cleaner assembly.
(Refer to Engine Mechanical System - &quo ...
