Kia Sorento: Relay Box (Engine Compartment) Component Location - Fuses And Relays - Body Electrical System - Kia Sorento XM 2011-2020 Service ManualKia Sorento: Relay Box (Engine Compartment) Component Location

Second Generation XM (2011-2020) / Kia Sorento XM 2011-2020 Service Manual / Body Electrical System / Fuses And Relays / Relay Box (Engine Compartment) Component Location

Component Location
1. Start relay #2 (W/O immo./smart key) / ACC relay (With smart key) 2. Start relay #1 3. Windshield deicer relay 4. Power outlet relay 5. Wiper relay (low) 6. Burgla ...

Relay Box (Engine Compartment) Inspection
1. Disconnect the negative (-) battery terminal. 2. Pull out the relay from the engine compartment relay box. Power Relay (Type A) ...
